◆ Design speed: 200-250m/min, width 1800mm-2500mm.

◆ Man-machine interface PLC automatic control, automatic switch the number of heating plates and pressure size, to ensure that adapt to a variety of different grams of corrugated paper corrugated peak intact.

◆ The surface of the heating plate is ground and plated with hard chromium. Width 600mm, 18-22 block selection.

◆ Hot section adopts hot pressing plate structure, according to the thickness of the production board, the pressure can be adjusted by pneumatic section (optional).

◆ Cotton webbing adopts double cylinder S-type cotton webbing tensioning device. Choose manual or automatic tape feed correction device.

◆ Drive unit adopts independent transmission. Electromagnetic speed motor or variable frequency motor drive. ◆ The surface of the driving roller is coated with wear-resistant rubber, with a herringbone structure and a medium height to ensure the smooth output of the cardboard.
