Function and features:

◆ Design speed: 250m/min.

◆ Effective width: 1400mm-2500mm.

◆ Roller: ф360mm (depending on the type of the roller), pressure roller ф 410mm, preheating roller ф400mm.

◆ Adopt negative pressure design, so that the core paper can be evenly compressed and attached to the surface of the corrugated roller, evenly coated with glue, so that the single-sided corrugated paper is better.

◆ Quick roller change, 15 minutes, when replacing the corrugated roller with an electric trolley drag load, into the machine, fixed on the machine base, quickly and easily complete the corrugated roller replacement.

◆ Corrugated roller, pressure roller, etc., with high stability of the air bag control system.

◆ The amount of glue is controlled by electric adjustment, the glue separation device is electric, and the glue coating system can operate independently when the host stops to prevent the glue from drying up.

◆ Mobile gluing system, in addition to convenient cleaning, more conducive to maintenance, repair work.

◆ Simple operation control system, touch screen operation interface, with color graphics display operation status, easy to operate.

◆ Built-in presetter with spray system to adjust core paper temperature and moisture.

◆ Corrugated roller, pressure roller, etc., with high stability of the air bag control system.

◆ The amount of glue is controlled by electric adjustment, the glue separation device is electric, and the glue coating system can operate independently when the host stops to prevent the glue from drying up.

◆ Mobile gluing system, in addition to convenient cleaning, more conducive to maintenance, repair work.

◆ Simple operation control system, touch screen operation interface, with color graphics display operation status, easy to operate.

◆ Built-in presetter with spray system to adjust core paper temperature and moisture.
