◆ Roller type leading edge paper feed structure, multi-wheel, multi-point suction paper feed, large friction, high speed, stable paper feed, accurate.

◆ Suction frequency conversion adjustment of air volume, wind pressure can be adjusted according to the size of the cardboard, increase the transmission stability and accuracy of thin paper board and curved cardboard.

◆ Paper feed rubber shaft, using pneumatic elastic paper feed, does not damage the strength of corrugated cardboard.

◆ The whole machine independent servo drive, can realize non-stop version change, improve the running accuracy and service life.

◆ Die cutting rubber pad imported by CUE company of the United States, easy installation and exchange, die cutting edge smooth, long service life, up to 12 million times or so, reduce the production cost.

◆ The die cutting rubber pad roll adopts a mechanical transverse device to move 40mm around, and a pneumatic device to control the tool move up and down, extending the service life of the rubber pad.

◆ Automatic line speed compensation, so that the rubber pad uniform wear, and equipped with rubber pad repair system, rubber pad can be used many times.

◆ The position of the feeder side baffle and the rear baffle box are controlled by computer and electric.

◆ Roller is made of high quality steel, internal tempering, surface grinding, hard chrome plating, and dynamic balance correction, smooth running.

◆ Die cutting roller phase, phase adjustment adopts planetary gear structure, PLC touch screen control and electric digital 360-degree adjustment.

◆ Import control system, Siemens.
