一．Linear Pneumatic Paper Unwinding Stand

1.The multi axis paper holder can accommodate multiple paper rolls and use pneumatic lifting to adjust the height of the paper rolls.

2.Optional 45 ° turning paper rack and electric hoist for paper feeding, reducing machine length and saving space.

二．Multi layer coating machine

The multi-layer gluing machine consists of several optical axis columns, which separate each layer of paper and apply double-sided glue evenly. The glue diaphragm pump circulates the glue.

三.Forming group

1. Coaxial transmission, all transmission parts have undergone quenching and surface chrome plating treatment.

2. The formed wheel wall panels are all treated with 45 # steel plate quenching and tempering, and the surface is chrome plated.

3. Cylinder balance pressure regulation. The cylinder stroke is adjustable and easy to adjust.

4. Adopting frequency conversion, motor, worm turbine reducer, stronger traction and smooth transmission.

5. The rack is welded with national standard channel steel and 10mm thick steel plate, with a 304 stainless steel tabletop on the upper surface

四.Punching Unit

1. It is possible to punch corners with a width of 30-80mm.

2. Commonly used are 90 degree punch, 90 degree buckle punch, and surround punch.

3. Touch screen and servo system control operation

4. High performance silent linear slide rail combined with high carbon steel linear optical axis and linear bearings

5. The punching die is made of Cr12Mov vacuum quenching and grinding, which is durable and long-lasting

6. The machine is equipped with a default punching die at the factory

五.Cutting groups

1. Touchscreen and servo system control operation, cutting accuracy can reach 1000 ± 1mm

2. Automatic alarm system, indicating the fault location to ensure safe operation.

3. Touch screen and servo system human-machine interface, with more user-friendly operation.

4. Automatic alarm, fault prompt, easy adjustment and maintenance. The touch screen is equipped with on duty and cumulative numbers, without the need for manual counting.

5. The aviation aluminum alloy material has been modulated and anodized surface treated, resulting in lightweight quality and smoother reciprocating operation, which improves the overall production speed and efficiency of the machine.
