◆ Automatic alignment instead of manually moving the baffle to guide the alignment, with non-contact infrared eye detection of materials, and self in the material. Core or material edge alignment, the operator does not need to go up and down the flyover to adjust the position of the baffle, using the baffle has about 10-15m alignment distance, and the automatic alignment system can be guided in 3-5m.

◆ Continuous paper replacement, there is a self-width discrimination device in the change order, which can be switched to the middle by itself. The heart guides right.

◆ With an operating panel, it can display the total width when the single tile paper is fitted, and the width can move the base paper holder to reach the fitting accuracy of the best core paper bottom paper.

◆ When changing orders, you can directly change orders, and the mechanical speed does not need to slow down for changing orders.

◆ Can perform two layers of single-tile line alignment, the use of the function of alignment, without the cooperation of the face paper.

◆ A small amount of energy consumption and noise, tension controller as long as 24V DC can achieve the effect of braking.

◆ High flatness of cardboard: tension detection is controlled by the actual tension, which is closer to the tension control of paper.

◆ No broken paper: The brake will control the brake force with a curved square to avoid the broken paper caused by the joint.

◆ Mechanical speed: 200-300m/min

◆ Effective width: 1800mm-2500mm

◆ Correction accuracy: ±3mm

◆ Detection method: full width infrared electric eye
