Safety operation：

● The use of the machinery to keep away from the fire source, spacious venue, ground leveling.

● This machine is used in single-phase asynchronous motor, please use the former to the grounding wire connected, joint can not be exposed, the electrical failure must ask professional repair.

● Normal working hours, walking is objects, in addition to working in other directions can not be someone close to lean.

● Mechanical work is prohibited to touch the operating position, remove or replace the component must stop, after work to be sure to turn off the power switch, is strictly prohibited equipment idle running.

● Read the instructions, compliance with the rules, adhere to maintenance.

Mechanical operation and matters needing attention

Examination before operation:

1、Confirm the cord is sequentially dressed, examine the line is in the sliding wheel.

 2、 From the bottom hole pressure within the through-line stand。

3、 After the spring tension and then up through two additional pieces in the middle of the shaft hole sprang。

4、The rope inside the roller to the head 。

5、in the roller chain to the axle inside the center hole penetration, pull the rope shaft hole。

6、Pull the rope head 。

7、 the cord down the outside of the roller wheel。

8、 to the inside, and then to the interference 。

9、heel anti-stick inside and then winding back bend wheel frame 。

10、 then the rope ends from the winding wire rack 。

11 、to the head end pressure pipe line from the bottom of the knob。

12、is wrapped around the back to tighten to 180 degrees.(Spring pressure to push the rope taut, see back cover map, and then push the secant knife will cut the rope, see back cover map)

cord tension adjustment:

1 、 When the cord to complete the wiring process, the hand holding the pressure below the frame line cord, let go about 20 cm down to observe the interference stick rebound position, the right back position in the bottom of the table should be about 5 cm.

2、 play pole adjustable: can guarantee interference stick their natural bounce, a little stretch.

3 、 cord tension adjustment see five: in place of line (figure 1), when the bundle of objects is bigger, can be a little relaxation in figure 1-3 butterfly nut; Whereas the butterfly nut.

If the bit is too high then transferred back pressed up spring, loosen the other hand, under normal circumstances must bear some of the tension of small objects. 2: Stick to tighten the level of intervention: intervention to ensure their own natural stick bounce, you can stretch a little bit. Eight: maintenance:

Life depends on maintenance of machinery and equipment and maintenance work, persisted in doing maintenance work is necessary.

1、 You must use the equipment every day before the operation site (except for off- chip parts, plus line knobs) 2-3 slider parts of lubricating drops.

2、every two months to add butter to the hole again.

3、The site is frequently observed screw loose.

4、 good equipment, especially parts of the cleaning head.

5、 Clamp knob can not have debris at the beak.

6、 Check the wound every three months time frame brake parts, adjusted (stepped up) braking.
